Product Description Of TPS22968DPUR

TPS22968DPUR is a small, ultra-low RON, dual-channel load switch with controlled turn on. TPS22968DPUR contains two N-channel MOSFETs that can operate over an input voltage range of 0.8V to 5.5V and can support a maximum continuous current of 4A per channel.

Specification Of TPS22968DPUR

Features Of TPS22968DPUR

• Integrated Dual Channel Load Switch
• Input Voltage Range: 0.8 V to 5.5 V
• VBIAS Voltage Range: 2.5 V to 5.5 V
– Ideal for 1S Battery Configuration
• Ultra-Low RON Resistance
– RON = 27 mΩ at VIN = 5 V (VBIAS = 5 V)
– RON = 25 mΩ at VIN = 3.3 V (VBIAS = 5 V)
– RON = 25 mΩ at VIN = 1.8 V (VBIAS = 5 V)
• 4-A Maximum Continuous Switch Current per Channel
• Low Quiescent Current
– 55 µA at VBIAS = 5 V (Both Channels)
– 55 µA at VBIAS = 5 V (Single Channel)
• Low Control Input Threshold Enables Use of 1.2-,1.8-, 2.5-, 3.3-V Logic
• Configurable Rise Time(1)
• Quick Output Discharge (QOD)(2) (Optional)
• SON 14-Pin Package with Thermal Pad
• ESD Performance Tested per JEDEC Standard
– 2-kV HBM and 1-kV CDM
• Latch-Up Performance Exceeds 100 mA per JESD 78, Class II
• GPIO Enable – Active High

Applications Of TPS22968DPUR

• Ultrabook™
• Notebooks and Netbooks
• Tablets
• Consumer Electronics
• Set-Top Boxes
• Telecom Systems

Typical Application Schematic Of TPS22968DPUR
