Product Description Of MT54A16G8080A00AC-32:A
MT54A16G8080A00AC-32:A HBM DRAM is optimized for high- bandwidth operation to a stack of multiple DRAM devices across a number of independent interfaces (channels). It is anticipated that each DRAM stack will support up to 8 channels.

Feature Of MT54A16G8080A00AC-32:A
VDDC = VDDQ = 1.2V ±5%
VPP = 2.5V –5%/+10%
Data rate: 2.8 Gb/s and 3.2 Gb/s
Peak bandwidths: 358 GB/s and 410 GB/s
ECC support: 9 memory bits per byte
8 independent channels with pseudo channel mode
DDR data (WDQS, RDQS)
Programmable READ latency (RL)
Programmable WRITE latency (WL)
Programmable parity latency (PL)
Burst length = 4
Write data mask function with single byte granularity
Data bus inversion (DBIac) for writes and reads
Parity for command/address and data monitoring
Auto precharge option for each burst access
Auto refresh mode (32ms, 8k cycles) with singlebank refresh option
Temperature sensor controlled self refresh rate
tRAS lockout
Programmable output driver strength
Unterminated clock, command, address, and datainterfaces
Temperature sensor with read‐out
IEEE 1500 standard serial test interface

Applications Of MT54A16G8080A00AC-32:A
Automotive
