L6201PSTR Integrated Circuit Chip DMOS Full Bridge Driver 4A Brushed DC Motor Drivers

L6201PSTR Integrated Circuit Chip DMOS Full Bridge Driver 4A Brushed DC Motor Drivers​

Product Description Of L6201PSTR

L6201PSTR is a full bridge driver for motor control applications realized in Multipower-BCD technology which combines isolated DMOS power transistors with CMOS and Bipolar circuits on the same chip. By using mixed technology it has been possible to optimize the logic circuitry and the power stage to achieve the best possible performance. The DMOS output transistors can operate at supply voltages up to 42V and efficiently at high switching speeds. All the logic inputs are TTL, CMOS and µC compatible. Each channel (half-bridge) of the L6201PSTR is controlled by a separate logic input, while a common enable controls both channels.

Specification Of L6201PSTR

Features Of L6201PSTR

High Efficiency
Internal logic power supply
Operating frequency up to 100 KHz
TTL compatible driver
Supply voltage up to 48V
Total RMS current up to: 1A
2A max peak current
Cross conduction protection
Thermal shutdown
RDS (ON) = 0.3 Ω (typical at 25°C)
