TLD2314EL Integrated Circuit Chip LITIX™ Basic High Side Driver IC 120mA LED Driver IC

TLD2314EL Integrated Circuit Chip LITIX™ Basic High Side Driver IC 120mA LED Driver IC​

Product Description Of TLD2314EL

TLD2314EL is a LITIX™ Basic three channel high side driver IC with integrated output stages.
TLD2314EL is designed to control LEDs with a current up to 120 mA. In typical automotive applications the device is capable to drive i.e. 3 red LEDs per chain (total 9 LEDs) with a current up to 60mA, which is limited by thermal cooling aspects. The output current is controlled practically independent of load and supply voltage changes.

Specification Of TLD2314EL

Features Of TLD2314EL

3 Channel device with integrated output stages (current sources), optimized to drive LEDs
Output current up to 120mA per channel
Low current consumption in sleep mode
PWM-operation supported via VS-pin
Output current adjustable via external low power resistor and possibility to connect PTC resistor for LED protection during over temperature conditions
Reverse polarity protection
Overload protection
Undervoltage detection
Open load and short circuit to GND diagnosis
Wide temperature range: -40 °C < Tj < 150 °C
PG-SSOP14 package with exposed heatslug

Applications Of TLD2314EL

Automotive instrument cluster
Roof control module with interior and ambient light control
