Product Description Of FSBB20CH60C
FSBB20CH60C is an advacned Motion SPM® 3 series that has newly developed to provide a very compact and high performance inverter solution for AC motor drives in low-power applications such as air conditioners. It combines optimized circuit protections and drives matched to low-loss IGBTs. The system reliability is further enhanced by the integrated under-voltage lock-out and over-current protection. The high speed built-in HVIC provides optocoupler- less single-supply IGBT gate driving capability that further reduces the overall size of the inverter system. Each phase leg current of the inverter can be monitored thanks to three separate negative dc terminals.

Specification Of FSBB20CH60C

Feature Of FSBB20CH60C
Very low thermal resistance by using Al2O3 DBC
Easy PCB layout thanks to built in bootstrap diodes
600V-20A 3-phase IGBT inverter bridge including control ICs for gate driving and protection
Three separate negative DC-link terminals for inverter current sensing applications
Single-grounded power supply for built-in HVICs
Isolation rating of 2500Vrms/min.

Applications Of FSBB20CH60C
Motion Control - Home Appliance/Industrial Motor
