ADS1293CISQ Integrated Circuit Chip Low-Power 3-Channel 24-Bit Analog Front-End For Biopotential Measurements

ADS1293CISQ Integrated Circuit Chip Low-Power 3-Channel 24-Bit Analog Front-End For Biopotential Measurements

Product Description Of ADS1293CISQ
ADS1293CISQ incorporates all features commonly required in portable, low-power medical, sports, and fitness electrocardiogram (ECG) applications. With high levels of integration and exceptional performance, the ADS1293CISQ enables the creation of scalable medical instrumentation systems at significantly reduced size, power, and overall cost.

ADS1293CISQ features three high-resolution channels capable of operating up to 25.6 ksps. Each channel can be independently programmed for a specific sample rate and bandwidth allowing users to optimize the configuration for performance and power. All input pins incorporate an EMI filter and can be routed to any channel through a flexible routing switch. Flexible routing also allows independent lead-off detection, right-leg drive, and Wilson/Goldberger reference terminal generation without the need to reconnect leads externally. A fourth channel allows external analog pace detection for applications that do not use digital pace detection.

Specification Of ADS1293CISQ

Feature Of ADS1293CISQ
Three High-Resolution Digital ECG Channels With
Simultaneous Pace Output
EMI-Hardened Inputs
Low Power: 0.3 mW/channel
Input-Referred Noise: 7 µVpp (40-Hz Bandwidth)
Input Bias Current: 175 pA
Data Rate: Up to 25.6 ksps
Differential Input Voltage Range: ±400 mV
Analog Supply Voltage: 2.7 V to 5.5 V
Digital I/O Supply Voltage: 1.65 V to 3.6 V
Right-Leg Drive Amplifier
AC and DC Lead-Off Detection
Wilson and Goldberger Terminals
ALARMB Pin for Interrupt Driven Diagnostics
Battery Voltage Monitoring
Built-In Oscillator and Reference
Flexible Power-Down and Standby Modes

Applications Of ADS1293CISQ
Portable 1/2/3/5/6/7/8/12-Lead ECG
Patient Vital Sign Monitoring: Holter, Event, Stress, and T elemedicine
Automated External Defibrillator
Sports and Fitness (Heart Rate and ECG)
