Product Description Of AMC1200BDUBR
AMC1200BDUBR is precision isolation amplifiers with an output separated from the input circuitry by a silicon dioxide (SiO2) barrier that is highly resistant to magnetic interference. This barrier has been certified to provide galvanic isolation of up to 4250 VPEAK (AMC1200B) or 4000 VPEAK (AMC1200) according to UL1577 and VDE V 0884-10. Used in conjunction with isolated power supplies, these devices prevent noise currents on a high common mode voltage line from entering the local ground and interfering with or damaging sensitive circuitry.
Specifications Of AMC1200BDUBR
1 Channel
4250 Vrms
Galvanic
100 kHz
108 dB
200 uV
5.5 V
2.7 V, 4.5 V
5.4 mA
- 40 C
+ 105 C
Gain Error:
0.075 %
Gain V/V:
8 V/V
Input Voltage Range - Max:
+/- 320 mV
Moisture Sensitive:
Yes
Operating Supply Voltage:
2.7 V to 5.5 V
Output Current per Channel:
20 mA
Output Type:
Differential
Pd - Power Dissipation:
44 mW
PSRR - Power Supply Rejection Ratio:
61 dB
Unit Weight:
851 mg
Features Of AMC1200BDUBR
±250-mV Input Voltage Range Optimized for Shunt Resistors
Very Low Nonlinearity: 0.075% Maximum at 5 V
Low Offset Error: 1.5 mV Maximum
Low Noise: 3.1 mVRMS Typical
Low High-Side Supply Current:
8 mA Maximum at 5 V
Input Bandwidth: 60 kHz Minimum
Fixed Gain: 8 (0.5% accuracy)
High Common Mode Rejection Ratio: 108 dB
3.3-V Operation on Low-Side
Certified Galvanic Isolation:
UL1577 and VDE V 0884-10 Approved
Isolation Voltage: 4250 VPEAK (AMC1200B)
Working Voltage: 1200 VPEAK
Transient Immunity: 10 kV/µs Minimum
Typical 10-Year Lifespan at Rated Working Voltage (see Application Report SLLA197)
Fully Specified Over the Extended Industrial Temperature Range
Applications Of AMC1200BDUBR
Shunt Resistor Based Current Sensing in:
Motor Control
Green Energy
Frequency Inverters
Uninterruptible Power Supplies
