Product Description Of EP53A8HQI

EP53A8HQI is an Enpirion® Power System on a Chip (PowerSoC) DC-DC converter. It integrates the inductor, MOSFET switches, small-signal circuits and compensation in an advanced 3mm x 3mm x 1.1mm 16-pin QFN package.

Integrated inductor ensures the complete power solution is fully characterized with the inductor carefully matched to the silicon and compensation network. EP53A8HQI enables a tiny solution footprint, low output ripple, low part-count, and high reliability, while maintaining high efficiency

Specification Of EP53A8HQI

Features Of EP53A8HQI

• Integrated Inductor Technology
• -40°C to +85°C Ambient Temperature Range
• 3mm x 3mm x 1.1mm QFN Package
• Total Solution Footprint ~ 21mm2
• Low VOUT Ripple for IO Compatibility
• High Efficiency, up to 94%
• VOUT Range 0.6V to VIN – 0.5V
• 1A Continuous Output Current
• 5 MHz Switching Frequency
• 3-pin VID for Glitch Free Voltage Scaling
• Internal soft start circuit
• Short Circuit and Over Current Protection
• UVLO and Thermal Protection
• IC Level Reliability in a PowerSoC Solution

Applications Of EP53A8HQI

• Portable Wireless and RF applications
• Wireless Broad Band Data Cards
• Solid State Storage Applications
• Noise and Space Sensitive Applications

Simplified Applications Circuit Of EP53A8HQI
