MEC1701Q-C2-SZ Integrated Circuit Chip Keyboard And Embedded Controller For Notebook PC

MEC1701Q-C2-SZ Integrated Circuit Chip Keyboard And Embedded Controller For Notebook PC​

Product Description Of MEC1701Q-C2-SZ

MEC1701Q-C2-SZ is keyboard and embedded controller designs customized for notebooks and tablet platforms. MEC1701Q-C2-SZ incorporates a 32-bit ARM Cortex M4F Microcontroller core with a closely-coupled SRAM for code and data. A secure bootloader is used to download the custom firmware image from the system’s shared SPI Flash device, thereby allowing system designers to customize the device’s behavior.

Specification Of MEC1701Q-C2-SZ

Features Of MEC1701Q-C2-SZ

• GPIO and Core Logic supports 3.3V and 1.8V Operation.
• Analog and PLL are 3.3V Operation only.
• ARM® Cortex®-M4 Processor Core
- 32-Bit ARM v7-M Instruction Set Architecture
- Hardware Floating Point Unit (FPU)
- Single 4GByte Addressing Space (Von Neumann Model)
- Little-Endian Byte Ordering
- Bit-Banding Feature Included
- NVIC Nested Vectored Interrupt Controller
• Internal Memory
- 64k Boot ROM
- Two blocks of SRAM, totaling 256KB, 320KB or 480KB
- 128 Bytes Battery Powered SRAM
- Non-volatile Read/Write Memory
• Four EC-based SMBus 2.0 Host Controllers
• Five independent Hardware Driven PS/2 Ports
• Two General Purpose Serial Peripheral Interface Controllers (ECGP-SPI)
• Clock Generator
- 32.768KHz Clock Source
- Programmable Clock Power Management Control and Distribution
- 48 MHz PLL
• Packages
- 144 Pin WFBGA RoHS Compliant package
