LM4040D20IDBZR Integrated Circuit Chip 45µA Precision Micropower Shunt Voltage Reference
LM4040D20IDBZR Integrated Circuit Chip 45µA Precision Micropower Shunt Voltage Reference
Description
Part Number:
LM4040D20IDBZR
Output Voltage::
2.048 V
Initial Accuracy::
1 %
Temperature Coefficient::
150 PPM / C
Shunt Current - Max::
15 MA
Accuracy::
8 MV
LM4040D20IDBZR Integrated Circuit Chip 45µA Precision Micropower Shunt Voltage Reference
Product Description Of LM4040D20IDBZR
LM4040D20IDBZR shunt voltage references are versatile, easy-to-use references that cater to a vast array of applications. The 2-pin fixed-output device requires no external capacitors for operation and is stable with all capacitive loads. Additionally, the reference offers low dynamic impedance, low noise, and low temperature coefficient to maintain a stable output voltage over a wide range of operating currents and temperatures. The LM4040D20IDBZR uses fuse and Zener-zap reverse breakdown voltage trim during wafer sort to offer four output voltage tolerances, ranging from 0.1% (maximum) for the A grade to 1% (maximum) for the D grade. Thus, a great deal of flexibility is offered to designers in choosing the best cost-to-performance ratio for their applications.
Specifications Of LM4040D20IDBZR
Shunt Precision References
2.048 V
1 %
150 PPM / C
15 mA
- 40 C
+ 125 C
Accuracy:
8 mV
Height:
1 mm
Length:
2.92 mm
Shunt Current - Min:
75 uA
Width:
1.3 mm
Unit Weight:
42 mg
Feature Of LM4040D20IDBZR
Fixed output voltages of 2.048V, 2.5V, 3V, 4.096V, 5V, 8.192V, and 10V
Tight output tolerances and low temperature coefficient
Maximum 0.1%, 100ppm/°C – A Grade
Maximum 0.2%, 100ppm/°C – B Grade
Maximum 0.5%, 100ppm/°C – C Grade
Maximum 1.0%, 150ppm/°C – D Grade
Low output noise: 35µVRMS typical
Wide operating current range: 45µA typical to 15mA
Stable with all capacitive loads; no output capacitor required
Available in extended temperature range: –40°C to 125°C
Applications Of LM4040D20IDBZR
Data-Acquisition Systems
Energy Infrastructure
Analog Input Module
Field Transmitters
Precision Audio
Automotive Electronics
