BSC500N20NS3G Integrated Circuit Chip 200V OptiMOS™ MOSFET Transistors TDSON-8 Package

BSC500N20NS3G Integrated Circuit Chip 200V OptiMOS™ MOSFET Transistors TDSON-8 Package
BSC500N20NS3G Integrated Circuit Chip 200V OptiMOS™ MOSFET Transistors TDSON-8 Package
BSC500N20NS3G Integrated Circuit Chip 200V OptiMOS™ MOSFET Transistors TDSON-8 Package BSC500N20NS3G Integrated Circuit Chip 200V OptiMOS™ MOSFET Transistors TDSON-8 Package

Large Image :  BSC500N20NS3G Integrated Circuit Chip 200V OptiMOS™ MOSFET Transistors TDSON-8 Package

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: BSC500N20NS3G
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TDSON-8
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

BSC500N20NS3G Integrated Circuit Chip 200V OptiMOS™ MOSFET Transistors TDSON-8 Package

Description
Part Number: BSC500N20NS3G Transistor Polarity:: N-Channel
Number Of Channels:: 1 Channel Vds - Drain-Source Breakdown Voltage:: 200 V
Id - Continuous Drain Current:: 24 A Rds On - Drain-Source Resistance:: 42 MOhms

BSC500N20NS3G Integrated Circuit Chip 200V OptiMOS™ MOSFET Transistors TDSON-8 Package



Product Description Of BSC500N20NS3G
BSC500N20NS3G 200 V OptiMOS™ MOSFET Transistors is performance leading benchmark technologies, perfectly suited for synchronous rectification in 48 V systems, DC-DC converters, uninterruptable power supplies (UPS) and inverters for DC motor drives.



Specifications Of BSC500N20NS3G

N-Channel

1 Channel

200 V

24 A

42 mOhms

- 20 V, + 20 V

2 V

20 nC

- 55 C

+ 150 C

96 W

Enhancement

Configuration:

Single

Fall Time:

7 ns

Forward Transconductance - Min:

19 S

Height:

1.27 mm

Length:

5.9 mm

Product Type:

MOSFETs

Rise Time:

5 ns

Typical Turn-Off Delay Time:

28 ns

Typical Turn-On Delay Time:

14 ns

Width:

5.15 mm

Unit Weight:

120.300 mg



Features Of BSC500N20NS3G
Industry’s lowest RDS(on)
Lowest Qg and Qgd
World’s lowest FOM RoHS compliant − halogen free MSL 1 rated

Benefits Of BSC500N20NS3G
Highest efficiency
Highest power density
Lowest board space consumption
Minimal device paralleling required
System cost improvement
Enviromentally friendly
Easy-to-design-in products



Applications Of BSC500N20NS3G
Synchronous rectification for AC-DC SMPS
Motor control for 48 V – 110 V systems
Isolated DC-DC converters
Lighting for 110 V AC networks
HID lamps
Class D audio amplifiers
Uninterruptable power supplies (UPS)
LED lighting power supply
48 V intermediate bus converter (IBC)
Complete system solutions for smart TVs
Consumer electronics
Secondary power distribution system
Telecommunication infrastructure
