RK1806 Integrated Circuit Chip Low Power Processor For Neural Network Inference FCCSP-420

RK1806 Integrated Circuit Chip Low Power Processor For Neural Network Inference FCCSP-420​

Product Description Of RK1806

RK1806 is a high-performance, low power processor for neural network inference. Especially, it is one of current leading solution for mobile device by providing complementary neural network hardware accelerator. Equipped with one powerful neural network process unit(NPU), it makes RK1806 easy programming and compatible with mainstream platforms in the market, such as caffe, tensorflow, and so on.

Features Of RK1806

Dual-core ARM Cortex-A35 CPU
ARM Neon Advanced SIMD (single instruction, multiple data) support for accelerated media and signal processing computation
Include VFP v4 hardware to support single and double-precision operations
128KB unified system L2 cache
Integrated 32KB L1 instruction cache, 32KB L1 data cache with 4-way set associative
One isolated voltage domain include
Separate power domains for CPU core system to support internal power switch
Video Decoder
- Support H.264/AVC Base/Main/High@level4.2
- Up to 1920x1080@60fps
Video Encoder
- Support H.264 video encoder at BP/MP/HP@level4.1
- Up to 1920x1080@30fps
Temperature sensor(TSADC)
- -40~125℃ temperature range and 5℃ temperature resolution
Successive approximation ADC (SARADC)
- 10-bit resolution
- Up to 1Msps sampling rate
- 4 single-ended input channelsI
