Product Description Of BQ24715RGRR
BQ24715RGRR is a NVDC-1 synchronous battery charge controller with low quiescent current, high light load efficiency for 2S or 3S Li-ion battery charging applications, offering low component count.
The power path management allows the system to be regulated at battery voltage but does not drop below the programmable system minimum voltage.
BQ24715RGRR provides N-channel ACFET and RBFET drivers for the power path management. It also provides driver of the external P-channel battery FET. The loop compensation is fully integrated.
Specifications Of BQ24715RGRR
Charge Management
Lithium-ion, Lithium Polymer
Adjustable
10 A
6 V to 24 V
VQFN-20
Unit Weight:
70 mg
Features Of BQ24715RGRR
6-24V Input SMBus NVDC-1 2-3S Battery Charger Controller
System Instant-on Operation with No Battery or Deeply Discharged Battery
Ultra-Fast Transient Response of 100 µs
Ultra-Low Quiescent Current of 500 µA and High PFM Light Load Efficiency 80% at 20mA load to Meet Energy Star and ErP Lot6
Switching Frequency: 600kHz/800kHz/1MHz
Programmable System/Charge Voltage (16 mV/step), Input/Charge Current (64 mA/step) with High Accuracy
±0.5% Charge Voltage Regulation
±3% Input/Charge Current Regulation
±2% 40x Input/16x Discharge Current Monitor Output
Support Battery LEARN Function
Maximize CPU Performance with Deeply Discharged Battery or No Battery
Integrated NMOS ACFET and RBFET Driver
20-pin 3.5 × 3.5 mm2 QFN Package
Applications Of BQ24715RGRR
Ultrabook, Notebook, and Tablet PC
Industrial and Medical Equipment
Portable Equipment
