CDCE913QPWRQ1 Integrated Circuit Chip Programmable 1-PLL VCXO Clock Synthesizer TSSOP-14

CDCE913QPWRQ1 Integrated Circuit Chip Programmable 1-PLL VCXO Clock Synthesizer TSSOP-14
CDCE913QPWRQ1 Integrated Circuit Chip Programmable 1-PLL VCXO Clock Synthesizer TSSOP-14 CDCE913QPWRQ1 Integrated Circuit Chip Programmable 1-PLL VCXO Clock Synthesizer TSSOP-14

Large Image :  CDCE913QPWRQ1 Integrated Circuit Chip Programmable 1-PLL VCXO Clock Synthesizer TSSOP-14

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: CDCE913QPWRQ1
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TSSOP-14
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union

CDCE913QPWRQ1 Integrated Circuit Chip Programmable 1-PLL VCXO Clock Synthesizer TSSOP-14

Description
Part Number: CDCE913QPWRQ1 Type: Spread Spectrum Clock Driver
Frequency - Max: 230MHz Voltage - Supply: 1.7V ~ 1.9V, 2.3V ~ 3.6V
Ratio - Input:Output: 1:3 Operating Temperature: -40°C ~ 125°C

CDCE913QPWRQ1 Integrated Circuit Chip Programmable 1-PLL VCXO Clock Synthesizer TSSOP-14​



Product Description Of CDCE913QPWRQ1

CDCE913QPWRQ1 is modular, phase-locked loop (PLL)-based programmable clock synthesizers. The CDCE913QPWRQ1 provide flexible and programmable options, such as output clocks, input signals, and control pins.
The CDCE913QPWRQ1 generate up to three output clocks from a single input frequency to enable both board space and cost savings. Additionally, with multiple outputs, the clock generator can replace multiple crystals with one clock generator.


Specification Of CDCE913QPWRQ1

Part Number: CDCE913QPWRQ1
3 Output
230 MHz
LVCMOS
Crystal, LVCMOS
TSSOP-14
160 MHz
1.7 V
1.9 V
- 40 ℃
+ 125 ℃
SMD/SMT
Features: I2C, Integrated EEPROM, Pin Programming, Spread Spectrum Clocking (SSC)
Operating Supply Current: 11 mA
Operating Supply Voltage: 1.8 V
Product Type: Clock Synthesizers / Jitter Cleaners
Type: 1-PLL VCXO Clock Synthesizer


Features Of CDCE913QPWRQ1

• In-system programmability and EEPROM
– Serial programmable volatile register
– Nonvolatile EEPROM to store customer settings
• Flexible input clocking concept
– External crystal: 8MHz to 32MHz
– On-chip VCXO: pull range ±150ppm
– Single-ended LVCMOS up to 160MHz
• Free selectable output frequency up to 230MHz
• Low-noise PLL core
– PLL loop filter components integrated
– Low period jitter (typical 50ps)
• Separate output supply pins: 3.3V and 2.5V
• Flexible clock driver
– Three user-definable control inputs [S0, S1, S2], for example, SSC selection, frequency switching, output enable, or power down
– Generates highly accurate clocks for video, audio, USB, IEEE1394, RFID, Bluetooth®, WLAN, Ethernet, and GPS
– Generates common clock frequencies used with TI- DaVinci™, OMAP™, DSPs
– Programmable SSC modulation
– Enables 0-PPM clock generation
• 1.8V device power supply
• Packaged in TSSOP
• Development and programming kit for easy PLL design and programming (TI Pro-Clock™)


Applications Of CDCE913QPWRQ1
• Clusters
• Head units
• Navigation systems
• Advanced driver assistance systems (ADAS)
