1EDC60H12AH Integrated Circuit Chip 1200V EiceDRIVER™ High Side Gate Driver IC PG-DSO-8

1EDC60H12AH Integrated Circuit Chip 1200V EiceDRIVER™ High Side Gate Driver IC PG-DSO-8
1EDC60H12AH Integrated Circuit Chip 1200V EiceDRIVER™ High Side Gate Driver IC PG-DSO-8
1EDC60H12AH Integrated Circuit Chip 1200V EiceDRIVER™ High Side Gate Driver IC PG-DSO-8 1EDC60H12AH Integrated Circuit Chip 1200V EiceDRIVER™ High Side Gate Driver IC PG-DSO-8

Large Image :  1EDC60H12AH Integrated Circuit Chip 1200V EiceDRIVER™ High Side Gate Driver IC PG-DSO-8

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: 1EDC60H12AH
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-DSO-8
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

1EDC60H12AH Integrated Circuit Chip 1200V EiceDRIVER™ High Side Gate Driver IC PG-DSO-8

Description
Part Number: 1EDC60H12AH Voltage - Isolation: 2500Vrms
Rise / Fall Time (Typ): 10ns, 9ns Voltage - Output Supply: 13V ~ 35V
Technology: Magnetic Coupling Operating Temperature: -40°C ~ 150°C (TJ)

1EDC60H12AH Integrated Circuit Chip 1200V EiceDRIVER™ High Side Gate Driver IC PG-DSO-8​



Product Description Of 1EDC60H12AH

1EDC60H12AH is EiceDRIVER™ 1200 V high-side single channel gate driver IC with typical 10.0 A source and 9.4 A sink currents in a wide-body package with CT technology for IGBT Modules.


Specification Of 1EDC60H12AH

Part Number: 1EDC60H12AH
IGBT, MOSFET Gate Drivers
High-Side
SMD/SMT
DSO-8-59
1 Driver
1 Output
6 A
3.1 V
17 V
Inverting, Non-Inverting
10 ns
9 ns
- 40 ℃
+ 125 ℃
Logic Type: CMOS
Operating Supply Current: 650 uA
Output Voltage: 13 V to 35 V
Pd - Power Dissipation: 25 mW, 400 mW
Product Type: Gate Drivers
Propagation Delay - Max: 330 ns


Features Of 1EDC60H12AH

Recognized under UL1577 with V ISO = 3000 V for 1 s
1200V coreless Transformer isolated Driver ICs
6 A rail-to-rail outputs
300 mil wide-body package for 8 mm creepage distance
Separate source/sink outputs


Applications Of 1EDC60H12AH
1-phase string inverter solutions
48 V intermediate bus converter (IBC)
EV charging
Hydrogen electrolysis
Power conversion
