ADV7125KSTZ140 Integrated Circuit Chip 330MHz Triple 8-Bit High Speed Video DAC
ADV7125KSTZ140 Integrated Circuit Chip 330MHz Triple 8-Bit High Speed Video DAC
Description
Part Number:
ADV7125KSTZ140
Resolution::
8 Bit
Sampling Rate::
330 MS/s
Number Of Channels::
3 Channel
Output Type::
Current
Interface Type::
Parallel
ADV7125KSTZ140 Integrated Circuit Chip 330MHz Triple 8-Bit High Speed Video DAC
Product Descriptions Of ADV7125KSTZ140
ADV7125KSTZ140 is a triple high speed, digital-to-analog converter (DAC) on a single monolithic chip. It consists of three high speed, 8-bit video DACs with complementary outputs, a standard TTL input interface, and a high impedance, analog output current source.
ADV7125KSTZ140 has three separate 8-bit-wide input ports. A single +5 V/+3.3 V power supply and clock are all that are required to make the device functional. The ADV7125KSTZ140 has additional video control signals, composite SYNC and BLANK as well as a power save mode.
Specifications Of ADV7125KSTZ140
8 bit
330 MS/s
3 Channel
Current
Parallel
3.3 V/5 V
3.3 V/5 V
- 40 C
+ 85 C
DNL - Differential Nonlinearity:
+/- 0.25 LSB
Height:
1.4 mm
INL - Integral Nonlinearity:
+/- 0.4 LSB
Length:
7 mm
Moisture Sensitive:
Yes
Operating Supply Voltage:
3.135 V to 5.25 V
Pd - Power Dissipation:
485 mW
Supply Voltage - Max:
5.25 V
Supply Voltage - Min:
3 V
Width:
7 mm
Unit Weight:
181.700 mg
Features Of ADV7125KSTZ140
330 MSPS throughput rate
Triple 8-bit DACs
RS-343A-/RS-170-compatible output
Complementary outputs
DAC output current range: 2.0 mA to 26.5 mA
TTL-compatible inputs
Internal reference (1.235 V)
Single-supply +5 V/+3.3 V operation
48-lead LQFP and LFCSP
Low power dissipation (30 mW minimum at 3 V)
Low power standby mode (6 mW typical at 3 V)
Industrial temperature range (−40°C to +85°C)
RoHS compliant packages
Qualified for automotive applications
Product Highlights Of ADV7125KSTZ140
330 MSPS (3.3 V only) throughput.
Guaranteed monotonic to eight bits.
Compatible with a wide variety of high resolution color graphics systems, including RS-343A and RS-170.
Applications Of ADV7125KSTZ140
Digital video systems
High resolution color graphics
Digital radio modulation
Image processing
Instrumentation
Video signal reconstruction
Automotive infotainment units
