BMI260 Sensor IC Ultra-Low Power Inertial Measurement Unit LGA-14 Package

BMI260 Sensor IC Ultra-Low Power Inertial Measurement Unit LGA-14 Package
BMI260 Sensor IC Ultra-Low Power Inertial Measurement Unit LGA-14 Package
BMI260 Sensor IC Ultra-Low Power Inertial Measurement Unit LGA-14 Package BMI260 Sensor IC Ultra-Low Power Inertial Measurement Unit LGA-14 Package

Large Image :  BMI260 Sensor IC Ultra-Low Power Inertial Measurement Unit LGA-14 Package

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: BMI260
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: LGA-14
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

BMI260 Sensor IC Ultra-Low Power Inertial Measurement Unit LGA-14 Package

Description
Part Number: BMI260 Package: LGA-14
Current Consumption: 685 µA Temperature Range: -40℃ - +85 °C

BMI260 Sensor IC Ultra-Low Power Inertial Measurement Unit LGA-14 Package



Product Descriptions Of BMI260
The ultra-low power BMI260 is an IMU consisting of a 16-bit tri-axial gyroscope and a 16-bit tri-axial accelerometer combining precise acceleration, angular rate measurement and intelligent on-chip motion-triggered interrupt features. This next-generation IMU provides fast, exact inertial sensing in smartphones and HMI applications. It provides highly accurate step counting, motion detection and is pin-to-pin compatible with the BMI160. Its industry’s first self-calibrating gyroscope with motionless CRT functionality compensates MEMS typical soldering drifts, ensuring post-soldering sensitivity errors down to ± 0.4%.



Specifications Of BMI260

Digital resolution

Accelerometer (A): 16-bit or 0.06 mg/LSB
Gyroscope (G): 16-bit or 0.004 dps/LSB

Programmable measurement range & sensitivity

(A): ±2 g: 16384 LSB/g
to
(A): ±16 g: 2048 LSB/g

(G): ±125 dps: 262.1 LSB/dps
to
(G): ±2000 dps: 16.4 LSB/dps

Zero-g/Zero-rate offset

(A): ±20 mg
(G): ±0.5 dps

Sensitivity Error

(A): ± 0.4%
(G): ± 0.4% (with CRT)

Temperature range

-40 … +85 °C

Temperature behaviour
(TCO; TCS)

(A): ±0.25 mg/K; ±0.004 %/K
(G): ±0.02 dps/K; ±0.02 %/K

Noise density

(A): 160 µg/√Hz
(G): 0.008 dps/√Hz

Offset vs PCB strain

(A): ±0.01 mg/µε
(G): ±1.5 mdps/µε

Filter BW (programmable)

(A): 5 Hz … 684 Hz
(G): 11 Hz … 751 Hz

Output data rate (ODR)

(A): 12.5 Hz … 1.6 kHz
(G): 25 Hz … 6.4 kHz

Digital inputs/outputs

2x SPI; 2x I2C; AUX I/F; OIS I/F
2x digital interrupts

Supply voltage

1.7 … 3.6 VDD
1.2 … 3.6 VDDIO

Current consumption

685 µA at full ODR (aliasing-free)

Package size

2.5 x 3.0 x 0.8 mm³
14 pin LGA



Applications Of BMI260
AR & VR
Smart home



Other Supply Product Types

Part Number

Package

CCG3-24-15SF

6-DIP MODULE

CCG3-24-12DF

6-DIP MODULE

CCG3-48-12DF

6-DIP MODULE

CCG3-48-15SF

6-DIP MODULE

CCG3-12-15DF

6-DIP MODULE

CCG3-12-03SF

6-DIP MODULE

CCG3-48-15DF

6-DIP MODULE

CCG3-12-12SF

6-DIP MODULE

CCG3-24-15DF

6-DIP MODULE

CCG3-48-05SF

6-DIP MODULE

CCG1R5-48-15SF

6-DIP MODULE

CCG1R5-48-12DF

6-DIP MODULE

CCG1R5-12-12SF

6-DIP MODULE

CCG1R5-48-03SF

6-DIP MODULE

CCG1R5-48-12SF

6-DIP MODULE

CCG1R5-24-12SF

6-DIP MODULE

CCG1R5-12-03SF

6-DIP MODULE

CCG1R5-48-05SF

6-DIP MODULE

CCG1R5-12-05SF

6-DIP MODULE

PYH200-72WS12

MODULE

PYH200-72WS24

MODULE

PYH200-72WS48

MODULE

CN300B110-15

MODULE

CN300B110-15/CO

MODULE

CN300B110-24

MODULE

CN200B110-15/CO

MODULE

CN200B110-15

MODULE

CN200B110-12/CO

MODULE

FAM65CR51XZ1

12-SIP

FAM65CR51XZ2

12-SIP



FAQ

Q: Are your products original?

A: Yes, all products are original, new original import is our purpose.

Q:Which Certificates do you have?

A:We are ISO 9001:2015 Certified Company and member of ERAI.

Q:Can you support small quantity order or sample?Is the sample free?

A:Yes,we support sample order and small order.Sample cost is different according to your order or project.

Q:How to ship my order? Is it safe?

A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.

Q:What about the lead time?

A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
