OPA313IDBVR Integrated Circuit Chip Single 5.5V 1MHz 50μA RRIO Operational Amplifier

OPA313IDBVR Integrated Circuit Chip Single 5.5V 1MHz 50μA RRIO Operational Amplifier

Product Description Of OPA313IDBVR
OPA313IDBVR single-channel operational amplifier represents a new generation of low-cost, general purpose, micro-power operational amplifiers. Featuring rail-to-rail input and very low noise (25 nV/√Hz at 1 kHz) makes this family very attractive for a variety of battery-powered applications that require a good balance between cost and performance. The low input bias current supports those op amps to be used in applications with megaohm source impedances.

Specifications Of OPA313IDBVR

Features Of OPA313IDBVR
Low IQ: 50 µA/ch
Wide Supply Range: 1.8 V to 5.5 V
Low Noise: 25 nV/√Hz at 1 kHz
Gain Bandwidth: 1 MHz
Low Input Bias Current: 0.2 pA
Low Offset Voltage: 0.5 mV
Unity-Gain Stable
Internal RF/EMI Filter
Extended Temperature Range:–40°C to +125°C

Applications Of OPA313IDBVR
Battery-Powered Instruments:
Consumer, Industrial, Medical
Notebooks, Portable Media Players
Sensor Signal Conditioning:
L oop-Powered
Notebooks, Portable Media Players
Wireless Sensors:
Home Security
Remote Sensing
Wireless Metering
