TLC59731DR Integrated Circuit Chip 8-Bit PWM LED Driver IC SOIC-8 LED Lighting Drivers

TLC59731DR Integrated Circuit Chip 8-Bit PWM LED Driver IC SOIC-8 LED Lighting Drivers​

Product Description Of TLC59731DR

TLC59731DR is an easy-to-use, 3-channel, 50-mA sink current LED driver. The single-wire, 600-kbps serial interface (EasySet) provides a solution for minimizing wiring cost.

TLC59731DR The LED driver provides 8-bit pulse width modulation (PWM) resolution and a simple gamma correction feature. The display repeat rate is achieved at 3.1 kHz (typical) with an integrated 6-MHz grayscale (GS) clock oscillator. The driver also provides unlimited cascading capability.

Specification Of TLC59731DR

Features Of TLC59731DR

Three Sink Current Channels
Current Capability:
– 50 mA per Channel
Grayscale (GS) Control With PWM:
– 8-Bit (256 Steps) With Simple Gamma Correction
Single-Wire Interface (EasySet™)
Power-Supply (VCC) Voltage Range:
– No Internal Shunt Regulator Mode: 3 V to 5.5 V
– Internal Shunt Regulator Mode: 3 V to 6 V
OUT Terminals Maximum Voltage: Up to 21 V
Integrated Shunt Regulator
Data Transfer Maximum Rate:
– Bits per Second (bps): 600 kbps
Internal GS Clock Oscillator: 6 MHz (Typical)
Display Repeat Rate: 3.1 kHz (Typical)
Output Delay Switching to Prevent Inrush Current
Unlimited Device Cascading
Operating Temperature: –40°C to 85°C

Applications Of TLC59731DR
RGB LED Cluster Lamp Displays
