HVDA541QDRQ1 Integrated Circuit Chip Automotive Catalog 5V CAN Transceiver SOIC-8

HVDA541QDRQ1 Integrated Circuit Chip Automotive Catalog 5V CAN Transceiver SOIC-8

Product Description Of HVDA541QDRQ1
HVDA541QDRQ1 is designed and qualified for use in automotive applications and meets or exceeds the specifications of the ISO 11898 High Speed CAN (Controller Area Network) Physical Layer standard (transceiver).

Specifications Of HVDA541QDRQ1

Features Of HVDA541QDRQ1
Qualified for Automotive Applications
AEC-Q100 Qualified With the Following Results:
Device Temperature Grade 1: –40°C to 125°C
Device HBM ESD Classification Level 3A
Device CDM ESD Classification Level C6
Device MM ESD Classification Level M4
Meets or Exceeds the Requirements of ISO 11898-2 and ISO 11898-5
GIFT/ICT Compliant
ESD Protection up to ±12 kV (Human-Body Model) on Bus Pins
I/O Voltage Level Adapting
SN65HVDA54x: Adaptable I/O Voltage Range (VIO) From 3 V to 5.33 V
SN65HVDA54x-5: 5 V VCC Device Version
Operating Modes:
Normal Mode: All Devices
Low Power Standby Mode (VCC Not Required, Only VIO Supply Needed Saving System Power)
SN65HVDA540: No Wake Up
SN65HVDA541: RXD Wake Up Request
Silent (Receive Only) Mode: HVDA542
High Electromagnetic Compliance (EMC)
Protection
Undervoltage Protection on VIO and VCC
Bus-Fault Protection of –27 V to 40 V
TXD Dominant State Time Out
RXD Wake Up Request Lock Out on CAN Bus Stuck Dominant Fault (HVDA541)
Thermal Shutdown Protection
Power-Up/Down Glitch-Free Bus I/O
High Bus Input Impedance When Unpowered (No Bus Load)

Applications Of HVDA541QDRQ1
SAE J2284 High-Speed CAN for Automotive Applications
SAE J1939 Standard Data Bus Interface
GMW3122 Dual-Wire CAN Physical Layer
ISO 11783 Standard Data Bus Interface
NMEA 2000 Standard Data Bus Interface
