MLX80020KDC-BAA-000-RE Integrated Circuit Chip 5mA Enhanced LIN Transceiver SOIC-8

MLX80020KDC-BAA-000-RE Integrated Circuit Chip 5mA Enhanced LIN Transceiver SOIC-8

Product Description Of MLX80020KDC-BAA-000-RE

MLX80020KDC-BAA-000-RE is a physical layer device for a single wire data link capable of operating in applications using baud rates from 1kBd to 20kBd. MLX80020KDC-BAA-000-RE has an improved EMI performance and ESD robustness.

Specification Of MLX80020KDC-BAA-000-RE

Features Of MLX80020KDC-BAA-000-RE

Compatible to LIN Physical Layer Specification Rev.2.x and SAE J2602
Baud rate up to 20 kBaud
Wide operating voltage range VS = 5 to 27 V
Very low standby current consumption of 10µA in sleep mode
Bus and local wake up capable with source recognition
Control output for voltage regulator with low on – resistance for switchable master termination
Low EME(emission) and high EMI(immunity) level
Fully compatible to 3.3V and 5V devices
Integrated termination resistor for LIN slave nodes
TxD dominant time out function
Sleep timer to guarantee the most power saving mode after power on or wake up in case of faulty passive microcontroller
High impedance Bus pin in case of loss of ground and undervoltage condition
Bus short to ground protection
