QCA7005-AL33 IoT Chip Automotive Powerline Communication IC QFN68 HPGP Single Chip

QCA7005-AL33 IoT Chip Automotive Powerline Communication IC QFN68 HPGP Single Chip

Product Description Of QCA7005-AL33

QCA7005-AL33 is Powerline Communications (PLC) portfolio of communication ICs. It is fully compliant with the HomePlug Green PHY (HPGP) specification. HomePlug's Green PHY specification meets the needs of the automotive (CCS charging standard), home, utility, and Smart Grid applications. The QCA7005-AL33 is interoperable up to the HPGP maximum data rate of 10 Mbps and offers lower power consumption, lower product complexity and reduced BOM costs.

Specification Of QCA7005-AL33

Features Of QCA7005-AL33

Compliant with HomePlug Green PHY specification
Interoperable with HomePlug AV specification and IEEE 1901 Standard up to the maximum HPGP data rate
Pin-compatible replacement for QCA7000
Operates on 240 VAC, 120 VAC, 24 VAC, and DC lines
Single chip solution with integrated analog front end and line driver
Lower cost and power consumption than existing HPAV solutions for lower data rates
Ideal for automotive charging applications
Extended temperature range for automotive and industrial, applications
Host interfaces: SPI (Slave) and UART
Boot from host or external FLASH memory
Dedicated FLASH memory port (SPI master)
Supports Robust OFDM (ROBO) mode modulation: 4 Mbps to 10 Mbps PHY rates
Powered from single 3.3 VDC rail with integrated Power Management Unit
RoHS Compliant: 8 x 8 mm 68 pin QFN package with wettable flanks
