ACS733KLATR-20AB Sensor IC 1MHz Bandwidth Galvanically Isolated Current Sensor IC SOIC-16
ACS733KLATR-20AB Sensor IC 1MHz Bandwidth Galvanically Isolated Current Sensor IC SOIC-16
Description
Part Number:
ACS733KLATR-20AB
Current Rating::
20 MA
Response Time::
0.2 Us
Operating Supply Voltage::
3.3 V
Maximum Operating Temperature::
+ 125 C
Minimum Operating Temperature::
- 40 C
ACS733KLATR-20AB Sensor IC 1MHz Bandwidth Galvanically Isolated Current Sensor IC SOIC-16
Product Description Of ACS733KLATR-20AB
ACS733KLATR-20AB current sensor family provides a 1MHz bandwidth with lightning fast 210nS response time sensing for AC or DC current sensing in automotive, industrial, commercial and communications systems. The device is designed for high frequency switching applications and can be used to replace high frequency current transformers.
Specifications Of ACS733KLATR-20AB
20 mA
0.2 us
3.3 V
Height:
2.35 mm
Length:
10.3 mm
Maximum Operating Temperature:
+ 125 C
Minimum Operating Temperature:
- 40 C
Moisture Sensitive:
Yes
Supply Voltage - Max:
3.46 V
Supply Voltage - Min:
3.14 V
Width:
7.5 mm
Features Of ACS733KLATR-20AB
AEC-Q100 automotive qualified
High bandwidth, 1 MHz analog output
Differential Hall sensing rejects common-mode fields
High-isolation SOIC16 wide body package provides galvanic isolation for high-voltage applications
Industry-leading noise performance with greatly improved bandwidth through proprietary amplifier and filter design
UL60950-1 (ed. 2) certified
Dielectric Strength Voltage = 3.6 kVRMS
Basic Isolation Working Voltage = 616 VRMS
Fast and externally configurable overcurrent fault detection
1 mΩ primary conductor resistance for low power loss and high inrush current withstand capability
Options for 3.3 V and 5 V single supply operation
Output voltage proportional to AC and DC current
Factory-trimmed sensitivity and quiescent output voltage for improved accuracy
Nearly zero magnetic hysteresis
Ratiometric output from supply voltage
