LTC3805IDD Integrated Circuit Chip Adjustable Frequency Current Mode Flyback DC/DC Controller
Product Description Of LTC3805IDD
LTC3805IDD is a current mode controller for flyback DC/DC converters designed to drive an N-channel MOSFET in high input and output voltage converter applications. Operating frequency and slope compensation can be programmed by external resistors. Programmable overcurrent sensing protects the converter from short-circuits. Soft-start can be programmed using an external capacitor and the soft-start capacitor also programs an automatic restart feature.
Specifications Of LTC3805IDD
|
Number of Outputs
|
|
|
Output Phases
|
|
|
Voltage - Supply (Vcc/Vdd)
|
|
|
Frequency - Switching
|
|
|
Duty Cycle (Max)
|
|
|
Synchronous Rectifier
|
|
|
Clock Sync
|
|
|
Control Features
|
|
|
Operating Temperature
|
|
|
Mounting Type
|
|
Features Of LTC3805IDD
VIN and VOUT Limited Only by External Components
Adjustable Slope Compensation
Adjustable Overcurrent Protection with Automatic Restart
Adjustable Operating Frequency (70kHz to 700kHz) with One External Resistor
Synchronizable to an External Clock
±1.5% Reference Accuracy
Current Mode Operation for Excellent Line and Load Transient Response
RUN Pin with Precision Threshold and Adjustable Hysteresis
Programmable Soft-Start with One External Capacitor
Low Quiescent Current: 360μA
Small 10-Lead MSOP and 3mm × 3mm DFN
Applications Of LTC3805IDD
Telecom Power Supplies
42V and 12V Automotive Power Supplies
Isolated Electronic Equipment
