HSEC8-140-01-L-RA-TR Connectors Generate™ High-Speed Edge Card Connector
Product Description Of HSEC8-140-01-L-RA-TR
HSEC8-140-01-L-RA-TR is a right-angle 0.80 mm pitch edge card connector. Featuring Samtec's Edge Rate® contact system, this series is designed for applications requiring high-mating cycles and 28 Gbps performance. Usable with a 1.60 mm (0.062") card, the HSEC8-RA is also compatible with the ECDP cable system for wire-to-board applications.
Specifications Of HSEC8-140-01-L-RA-TR
|
Card Type
|
Non Specified - Dual Edge
|
|
Gender
|
|
|
Number of Positions/Bay/Row
|
|
|
Number of Positions
|
|
|
Card Thickness
|
|
|
Number of Rows
|
|
|
Pitch
|
|
|
Read Out
|
|
|
Mounting Type
|
Surface Mount, Right Angle
|
|
Termination
|
|
|
Contact Material
|
|
|
Contact Finish
|
|
|
Contact Finish Thickness
|
|
|
Contact Type
|
|
|
Color
|
|
|
Operating Temperature
|
|
|
Material - Insulation
|
Liquid Crystal Polymer (LCP)
|
Features Of HSEC8-140-01-L-RA-TR
28 Gbps NRZ performance
Rugged Edge Rate® contact
Single-ended and differential pairs
Card slot: .062" (1.60 mm)
Current rating: 2.6 A max
Voltage rating: 175 VAC/247 VDC max
Solder tabs for mechanical strength
Optional board locks and cable latching features
Extended Life Product™ (E.L.P.™)
Automotive A-Series product available
