LT3010EMS8E-5 Integrated Circuit Chip 50mA 3V To 80V Low Dropout Micropower Linear Regulator
Product Description Of LT3010EMS8E-5
LT3010EMS8E-5 is a high voltage, micropower low dropout linear regulator. The device is capable of supplying 50mA output current with a dropout voltage of 300mV. Designed for use in battery-powered or high voltage systems, the low quiescent current (30μA operating and 1μA in shutdown) makes the LT3010EMS8E-5 an ideal choice. Quiescent current is also well controlled in dropout.
Specifications Of LT3010EMS8E-5
|
Number of Regulators
|
|
|
Voltage - Input (Max)
|
|
|
Voltage - Output (Min/Fixed)
|
|
|
Voltage Dropout (Max)
|
|
|
Current - Output
|
50mA
|
|
PSRR
|
|
|
Control Features
|
|
|
Protection Features
|
Over Current, Over Temperature, Reverse Polarity
|
|
Operating Temperature
|
|
Features Of LT3010EMS8E-5
Wide Input Voltage Range: 3V to 80V
Low Quiescent Current: 30μA
Low Dropout Voltage: 300mV
Output Current: 50mA
Thermally Enhanced 8-Lead MSOP Package
No Protection Diodes Needed
Fixed Output Voltage: 5V (LT3010-5)
Adjustable Output from 1.275V to 60V (LT3010)
1μA Quiescent Current in Shutdown
Stable with 1μF Output Capacitor
Stable with Aluminum, Tantalum or Ceramic Capacitors
Reverse-Battery Protection
No Reverse Current Flow from Output
Thermal Limiting
AEC-Q100 Qualified for Automotive Applications
Applications Of LT3010EMS8E-5
Low Current High Voltage Regulators
Regulator for Battery-Powered Systems
Telecom Applications
Automotive Applications
