UCC28056CDBVR Integrated Circuit Chip High Performance Single-Phase Transition-Mode PFC Controller

UCC28056CDBVR Integrated Circuit Chip High Performance Single-Phase Transition-Mode PFC Controller

Product Description Of UCC28056CDBVR
UCC28056CDBVR device drives PFC boost stages based on an innovative mixed mode method that operates in transition mode (TM) at full load and transitions seamlessly into discontinuous conduction mode (DCM) at reduced load, automatically reducing switching frequency. This device incorporates burst mode operation to further improve light load performance, enabling systems to meet challenging energy standards while eliminating the need to switch off the PFC. UCC28056CDBVR can drive a PFC power stage up to 300 W, ensuring sinusoidal line input current with low distortion, close to unity power factor.

Specifications Of UCC28056CDBVR

Features Of UCC28056CDBVR
Ultra-low no-load input power enables < 80-mW standby power at 230 VAC in PFC+LLC system
Excellent light load efficiency and high efficiency over wide range of load due to multi-mode TM and DCM control
Enables low system cost through FET drain valley synchronized turn-on which eliminates need for second winding on the boost inductor
Enables compliance to green power standards without disabling PFC
EuP Lot 6 Tier 2, CoC Ver. 5 Tier 2, Energy Star Ver. 6.1, DoE Level VI
Burst mode with soft-entry and soft-exit periods enables ultra-low audible noise output
Enhanced error amplifier, responds rapidly to load steps without degrading input current distortion
User adjustable valley delay ensures valley switching
Low start-up current consumption (<46 µA)
Wide VCC range 8.5 V to 34 V
Cycle-by-cycle current limit
Second independent output over-voltage protection
Integrated over-temperature protection
Create a custom design using the UCC28056 device with the WEBENCH® Power Designer

Applications Of UCC28056CDBVR
Desktop computing and digital TV
Gaming, set top box and AC adapter front end
LED drivers and luminaries
Industrial and medical power supplies, e-bike chargers, power tools chargers

Other Supply Product Types

FAQ

Q: Are your products original?

A: Yes, all products are original, new original import is our purpose.

Q:Which Certificates do you have?

A:We are ISO 9001:2015 Certified Company and member of ERAI.

Q:Can you support small quantity order or sample?Is the sample free?

A:Yes,we support sample order and small order.Sample cost is different according to your order or project.

Q:How to ship my order? Is it safe?

A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.

Q:What about the lead time?

A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
