ISOW7842DWER Integrated Circuit Chip 5000Vrms Quad Channel Digital Isolators SOIC16

ISOW7842DWER Integrated Circuit Chip 5000Vrms Quad Channel Digital Isolators SOIC16​

Product Description Of ISOW7842DWER

ISOW7842DWER is high-performance, quad-channel reinforced digital isolators with an integrated high-efficiency power converter. The integrated DC-DC converter provides up to 650 mW of isolated power at high efficiency and can be configured for various input and output voltage configurations. Therefore these devices eliminate the need for a separate isolated power supply in space-constrained isolated designs.

Specification Of ISOW7842DWER

Features Of ISOW7842DWER

• 100 Mbps data rate
• Robust isolation barrier:
– >100-Year projected lifetime at 1 kVRMS working voltage
– Up to 5000 VRMS isolation rating
– Up to 10 kVPK surge capability
– ±100 kV/µs minimum CMTI
• Integrated high-efficiency DC-DC converter with on-chip transformer
• 3-V to 5.5-V Wide input supply range
• Regulated 5-V or 3.3-V output
• Up to 0.65-W output power
• 5 V to 5 V; 5 V to 3.3 V: Available load current ≥ 130 mA
• 3.3 V to 3.3 V: Available load current ≥ 75 mA
• 3.3 V to 5 V: Available load current ≥ 40 mA
• Soft-start to limit inrush current
• Overload and short-circuit protection
• Thermal shutdown
• Default output: High and Low options
• Low propagation delay: 13 ns Typ (5-V supply)
• Robust electromagnetic compatibility (EMC)
– System-level ESD, EFT, and surge immunity
– ±8 kV IEC 61000-4-2 contact discharge protection across isolation barrier
– Low emissions
• 16-pin Wide SOIC package
• Extended temperature range: –40°C to +125°C

Applications Of ISOW7842DWER
• Industrial automation
• Motor control
• Grid infrastructure
• Medical equipment
• Test and measurement
