Product Description Of TLS820F0EL
TLS820F0EL is a high performance very low dropout linear voltage regulator for 5 V supply in a PG-SSOP-14 package.

With an input voltage range of 3 V to 40 V and very low quiescent of only 40 μA, these regulators are perfectly suitable for automotive or any other supply systems connected to the battery permanently. The TLS820F0 V50 provides an output voltage accuracy of 2 % and a maximum output current up to 200 mA.

The new loop concept combines fast regulation and very good stability while requiring only one small ceramic capacitor of 1 μF at the output. At currents below 100 mA the device will have a very low typical dropout voltage of only 70 mV. The operating range starts already at input voltages of only 3 V (extended operating range). This makes the TLS820F0 V50 also suitable to supply automotive systems that need to operate during cranking condition.

The output voltage is supervised by the Reset feature, including Undervoltage Reset, delayed Reset at Power-On and an adjustable lower Reset Threshold. In addition, a Watchdog circuit with flexible timings is integrated to monitor the microcontroller’s operation. Output current limitation and overtemperature shutdown are implemented to protect the device against immediate damage.

Specifications Of TLS820F0EL

Features Of TLS820F0EL
Wide Input Voltage Range from 3.0 V to 40 V
Fixed Output Voltage 5 V
Output Current Capability up to 200 mA
Output Voltage Precision ≤ ± 2 %
Ultra Low Current Consumption typ. 40 μA
Very Low Dropout Voltage typ. 70 mV @100 mA
Stable with Ceramic Output Capacitor of 1 μF
Delayed Reset at Power-On with 2 Programmable Delay Times 8.5 ms/ 16.5 ms
Adjustable Reset Threshold down to 2.50 V
Watchdog with flexible timings and current dependant deactivation:
16 ms / 32 ms / 48 ms / 96 ms, Activated at IQ > 5.5 mA)
Enable, Undervoltage Reset, Overtemperature Shutdown
Output Current Limitation
Wide Temperature Range
Green Product (RoHS compliant)
AEC Qualified
PG-SSOP-14

Applications Of TLS820F0EL
Automotive general ECUs
Small ECUs where SBC or DCDC are not used
Secondary supply in ECU (E.g. for CAN)
Dashboard, cluster, climate control, fuel pump, ADAS
Automotive 48 V battery management system (BMS)
Automotive battery management system (BMS)
Automotive high-voltage battery management system (BMS)
Automotive primary power distribution unit
