TPS74612PQWDRBRQ1 Integrated Circuit Chip Automotive 1A LDO Low-Dropout Voltage Regulator With Power-Good

TPS74612PQWDRBRQ1 Integrated Circuit Chip Automotive 1A LDO Low-Dropout Voltage Regulator With Power-Good

Product Description Of TPS74612PQWDRBRQ1
TPS74612PQWDRBRQ1 is a 1A, ultra-low-dropout regulator (LDO) with power-good functionality. This device is available in a small 6-pin, 2mm × 2mm WSON package and a small 8-pin, 3mm × 3mm VSON package with wettable flanks to facilitate optical inspection. TPS74612PQWDRBRQ1 consumes low quiescent current and provides fast line and load transient performance.

TPS74612PQWDRBRQ1 is a flexible device for post-regulation by supporting an input voltage range from 1.5V to 6.0V and an externally adjustable output range of 0.55V to 5.5V. The device also features fixed output voltages for powering common voltage rails.

Product Attributes Of TPS74612PQWDRBRQ1

Features Of TPS74612PQWDRBRQ1
AEC-Q100 qualified for automotive applications:
Temperature grade 1: –40°C to +125°C, TA
Device operating junction temperature range:
–40°C to +150°C
Input voltage range: 1.5V to 6.0V
Output voltage range:
Fixed option: 0.65V to 5.0V
Adjustable option: 0.55V to 5.5V
High PSRR: 38dB at 100kHz
Output accuracy: ±0.85% typical, ±1.5% maximum
Power-good output options:
Open-drain or push-pull
Ultra-low dropout:
265mV (max) at 1A (3.3VOUT)
Stable with a 1µF or larger capacitor
Low IQ: 25µA (typical)
Active output discharge
Functional Safety-Capable
Documentation available to aid functional safety system design
Low thermal resistance:
DRV (6-pin WSON), RθJA = 80.3°C/W
DRB (8-pin VSON), RθJA = 55.5°C/W

Applications Of TPS74612PQWDRBRQ1
Automotive head units
Front and rear cameras
Automotive cluster displays
Telematics control units
Medium, short range radar
