AD5165BUJZ100 Integrated Circuit Chip 1.8V Logic Level Digital Potentiometers DigiPOT

AD5165BUJZ100 Integrated Circuit Chip 1.8V Logic Level Digital Potentiometers DigiPOT

Product Description Of AD5165BUJZ100

AD5165BUJZ100 is 256-Position, Ultralow Power 1.8V Logic Level Digital Potentiometer. It provides a compact 2.9 mm × 2.8 mm packaged solution for 256-position adjustment applications.

AD5165BUJZ100 perform the same electronic adjustment function as mechanical potentiometers or variable resistors, with enhanced resolution, solid-state reliability, and superior low temperature coefficient performance. The AD5165BUJZ100’s supply voltage requirement is 2.7 V to 5.5 V, but its logic voltage requirement is 1.8 V to VDD. The AD5165BUJZ100 consumes very low quiescent power during standby mode and is ideal for battery-operated applications.

Specification Of AD5165BUJZ100

Features Of AD5165BUJZ100

Ultralow standby power
IDD= 50 nA typical
256-position
End-to-end resistance 100 Ω
Logic high voltage 1.8 V
Power supply 2.7 V to 5.5 V
Low temperature coefficient 35 ppm/°C
Compact thin 8-lead TSOT-8
(2.9 mm × 2.8 mm) package
Simple 3-wire digital interface
Wide operating temperature: -40°C to +125°C
Pin-to-pin compatible to
AD5160 with CS inverted

Applications Of AD5165BUJZ100
Battery-operated electronics adjustment
Remote utilities meter adjustment
Mechanical potentiometer replacement
Transducer circuit adjustment
Automotive electronics adjustment
Gain control and offset adjustment
System calibration
VCXO adjustment

Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
