AMC1301DWVR Integrated Circuit Chip Precision Reinforced Isolated Amplifier For Current Sensing

AMC1301DWVR Integrated Circuit Chip Precision Reinforced Isolated Amplifier For Current Sensing

Product Description Of AMC1301DWVR
AMC1301DWVR is a precision, isolated amplifier with an output separated from the input circuitry by an isolation barrier that is highly resistant to magnetic interference. This barrier is certified to provide reinforced isolation of up to 7070 V PEAK according to the DIN EN IEC 60747-17 (VDE 0884-17) and UL1577 standards, and supports a working voltage up to 1 kV RMS.

The isolation barrier separates parts of the system that operate on different common-mode voltage levels and protects the low-side from voltage levels that can cause electrical damage and are potentially harmful to an operator.

Product Attributes Of AMC1301DWVR

Feature Of AMC1301DWVR
±250-mV input voltage range optimized for current measurements using shunt resistors
Fixed gain: 8.2 V/V
Low DC errors:
Offset error: ±0.2 mV (max)
Offset drift: ±3 µV/°C (max)
Gain error: ±0.3% (max)
Gain drift: ±50 ppm/°C (max)
Nonlinearity: 0.03% (max)
3.3-V operation on high-side and low-side
System-level diagnostic features
Safety-related certifications:
7070-V PK reinforced isolation per DIN EN IEC 60747-17 (VDE 0884-17)
5000-V RMS isolation for 1 minute per UL1577
Fully specified over the extended industrial temperature range: –40°C to +125°C

Applications Of AMC1301DWVR
Shunt-resistor-based current sensing in:
– Motor drives
– Frequency inverters
– Uninterruptible power supplies
