QS3VH253QG8 Integrated Circuit Chip High Bandwidth Bus Switch With Low ON-Resistance
Product Description Of QS3VH253QG8
QS3VH253QG8 HotSwitch dual 4:1 multiplexer/demultiplexer is a high bandwidth bus switch with very low ON-resistance, resulting in under 250ps propagation delay through the switch. The combination of near-zero propagation delay, high OFF impedance, and overvoltage tolerance makes the QS3VH253QG8 ideal for high-performance communication applications. The QS3VH253QG8 operates from -40 °C to +85 °C.
Product Attributes Of QS3VH253QG8
|
Type
|
|
|
Circuit
|
|
|
Independent Circuits
|
|
|
Voltage Supply Source
|
|
|
Voltage - Supply
|
|
|
Operating Temperature
|
|
|
Mounting Type
|
|
Feature Of QS3VH253QG8
N-channel FET switches with no parasitic diode to VCC
Isolation under power-off conditions
No DC path to VCC or GND
5V tolerant in OFF and ON state
5V tolerant I/Os
Low RON - 4Ω typical
Flat RON characteristics over operating range
Rail-to-rail switching 0V to 5V
Bidirectional dataflow with near-zero delay: No added ground bounce
Excellent RON matching between channels
VCC operation: 2.3V to 3.6V
High bandwidth - up to 500MHz
LVTTL-compatible control Inputs
Undershoot clamp diodes on all switch and control Inputs
Low I/O capacitance, 4pF typical
Available in 16-pin QSOP and TSSOP packages
Applications Of QS3VH253QG8
Hot-swapping
Multiplexing/demultiplexing
Low distortion analog switch
Replaces mechanical relay
ATM 25/155 switching
