Product Details:
|
Part Number: | OPA2378AIDCNR | Slew Rate: | 0.4V/µs |
---|---|---|---|
Gain Bandwidth Product: | 900 KHz | Current - Input Bias: | 150 PA |
Voltage - Input Offset: | 20 µV | Current - Supply: | 125µA (x2 Channels) |
OPA2378AIDCNR Integrated Circuit Chip Dual Low-Noise 900KHz Precision Operational Amplifier
Product Description Of OPA2378AIDCNR
OPA2378AIDCNR represent a new generation of Zerø-Drift, microPOWER operational amplifiers that use a proprietary auto-calibration technique to provide minimal input offset voltage (20µV) and offset voltage drift (0.1µV/°C). The combination of low input voltage noise, high gain bandwidth (900kHz), and low power (150µA max) enable these devices to achieve optimum performance for low-power precision applications. In addition, the excellent PSRR performance, coupled with a wide input supply range of 2.2V to 5.5V and rail-to-rail input and output, makes it an outstanding choice for single-supply applications that run directly from batteries without regulation.
Product Attributes Of OPA2378AIDCNR
Amplifier Type |
Zero-Drift |
Number of Circuits |
2 |
Output Type |
Rail-to-Rail |
Slew Rate |
0.4V/µs |
Gain Bandwidth Product |
900 kHz |
Current - Input Bias |
150 pA |
Voltage - Input Offset |
20 µV |
Current - Supply |
125µA (x2 Channels) |
Current - Output / Channel |
30 mA |
Voltage - Supply Span (Min) |
2.2 V |
Voltage - Supply Span (Max) |
5.5 V |
Operating Temperature |
-40°C ~ 125°C |
Features Of OPA2378AIDCNR
Low Noise
0.4µVPP, 0.1Hz to 10Hz
20nV/√Hz at 1kHz
Zero Drift Series
Low offset voltage: 20µV
Low Offset Drive: 0.1µV/°C
Quiescent Current: 125µA
Gain Bandwidth: 900kHz
Rail-to-Rail Input/Output
EMI Filtering
Supply voltage: 2.2V to 5.5V
Miniature packages: SC70 and SOT23 SC70 and SOT23
Applications Of OPA2378AIDCNR
Portable Medical Devices
Glucose Meters
Oxygen metering
Heart rate monitors
Weight scales
Battery Powered Instruments
Thermopile Modules
Handheld Test Equipment
Sensor Signal Conditioning
