IPC100N04S5-2R8 Integrated Circuit Chip 40V N-Channel Automotive MOSFET Transistors

IPC100N04S5-2R8 Integrated Circuit Chip 40V N-Channel Automotive MOSFET Transistors
IPC100N04S5-2R8 Integrated Circuit Chip 40V N-Channel Automotive MOSFET Transistors
IPC100N04S5-2R8 Integrated Circuit Chip 40V N-Channel Automotive MOSFET Transistors IPC100N04S5-2R8 Integrated Circuit Chip 40V N-Channel Automotive MOSFET Transistors

Large Image :  IPC100N04S5-2R8 Integrated Circuit Chip 40V N-Channel Automotive MOSFET Transistors

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: IPC100N04S5-2R8
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-TDSON-8
Delivery Time: 3-5 work days
Payment Terms: TT
Supply Ability: 10000 Pieces per Day
Contact Now

IPC100N04S5-2R8 Integrated Circuit Chip 40V N-Channel Automotive MOSFET Transistors

Description
Part Number: IPC100N04S5-2R8 Drain To Source Voltage (Vdss): 40 V
Current - Continuous Drain (Id) @ 25°C: 100A (Tc) Drive Voltage (Max Rds On, Min Rds On): 7V, 10V
Rds On (Max) @ Id, Vgs: 2.8mOhm @ 50A, 10V Vgs(th) (Max) @ Id: 3.4V @ 30µA

IPC100N04S5-2R8 Integrated Circuit Chip 40V N-Channel Automotive MOSFET Transistors



Product Description Of IPC100N04S5-2R8
IPC100N04S5-2R8 is 40V 2.8mΩ N-Channel OptiMOS™-5 Automotive MOSFET Transistors.



Product Attributes Of IPC100N04S5-2R8

FET Type

N-Channel

Technology

MOSFET (Metal Oxide)

Drain to Source Voltage (Vdss)

40 V

Current - Continuous Drain (Id) @ 25°C

100A (Tc)

Drive Voltage (Max Rds On, Min Rds On)

7V, 10V

Rds On (Max) @ Id, Vgs

2.8mOhm @ 50A, 10V

Vgs(th) (Max) @ Id

3.4V @ 30µA

Gate Charge (Qg) (Max) @ Vgs

45 nC @ 10 V

Vgs (Max)

±20V

Input Capacitance (Ciss) (Max) @ Vds

2600 pF @ 25 V

Power Dissipation (Max)

75W (Tc)

Operating Temperature

-55°C ~ 175°C (TJ)

Grade

Automotive

Qualification

AEC-Q101

Mounting Type

Surface Mount



Features Of IPC100N04S5-2R8
OptiMOS™ - power MOSFET for automotive applications
N-channel - Enhancement mode - Normal Level
AEC Q101 qualified
MSL1 up to 260°C peak reflow
175°C operating temperature
Green Product (RoHS compliant)
100% Avalanche tested



Other Supply Product Types

Part Number Package
ISSI20R11HXUMA1 PG-DSO-8
ISSI30R12HXUMA1 PG-DSO-16
4DIR2400HAXUMA1 PG-DSO-16
CY15V116QSN-108BKXI FBGA-24
4DIR0400HAXUMA1 PG-DSO-16
S70KL1282DPBHV023 24-FBGA
S70KL1282GABHV023 24-FBGA
S70KL1282DPBHB020 24-FBGA
S70KL1282DPBHB023 24-FBGA
S70KS1282GABHB020 24-FBGA
S70KS1282GABHA020 24-FBGA
S70KS1282GABHI020 24-FBGA
S70KL1282DPBHA020 24-FBGA
RV1S9231ACCSP-10YV#SC0 5-LSSO
RV1S9353ACCSP-120V#SC0 8-SMD
ISSI30R11HXUMA1 PG-DSO-16
4DIR0401HAXUMA1 PG-DSO-16
4DIR1400HAXUMA1 PG-DSO-16
4DIR1421HAXUMA1 PG-DSO-16
4DIR1420HAXUMA1 PG-DSO-16
STM32H7R7L8H6H TFBGA-225
STM32H7R7Z8J6 UFBGA-144
STM32H7S7I8K6 UFBGA-201
STM32H7S7I8T6 LQFP-176
STM32H7S7L8H6 TFBGA-225
STM32H7S7L8H6H TFBGA-225
STM32H7S7Z8J6 UFBGA-144
STM32H7S3A8I6 UFBGA-169
STM32H7S3I8K6 UFBGA-201
STM32H7S3I8T6 LQFP-176



FAQ

Q: Are your products original?

A: Yes, all products are original, new original import is our purpose.

Q:Which Certificates do you have?

A:We are ISO 9001:2015 Certified Company and member of ERAI.

Q:Can you support small quantity order or sample?Is the sample free?

A:Yes,we support sample order and small order.Sample cost is different according to your order or project.

Q:How to ship my order? Is it safe?

A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.

Q:What about the lead time?

A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
