Product Description Of EPM240F100I5N
EPM240F100I5N MAX II instant-on, non-volatile CPLDs is based on a 0.18-µm,6-layer-metal-flash process, with densities from 240 to 2,210 logic elements (LEs) (128to 2,210 equivalent macrocells) and non-volatile storage of 8 Kbits. MAX II devicesoffer high I/O counts, fast performance, and reliable fitting versus other CPLDarchitectures. Featuring MultiVolt core, a user flash memory (UFM) block, andenhanced in-system programmability (ISP), MAX II devices are designed to reducecost and power while providing programmable solutions for applications such as busbridging, I/O expansion, power-on reset (POR) and sequencing control, and deviceconfiguration control.

Product Attributes Of EPM240F100I5N

Features Of EPM240F100I5N
Low-cost, low-power CPLD
Instant-on, non-volatile architecture
Standby current as low as 25 µA
Provides fast propagation delay and clock-to-output times
Provides four global clocks with two clocks available per logic array block (LAB)
UFM block up to 8 Kbits for non-volatile storage
MultiVolt core enabling external supply voltages to the device of either3.3 V/2.5 V or 1.8 V
MultiVolt I/O interface supporting 3.3-V, 2.5-V, 1.8-V, and 1.5-V logic levels
Bus-friendly architecture including programmable slew rate, drive strength,bus-hold, and programmable pull-up resistors
Schmitt triggers enabling noise tolerant inputs (programmable per pin)
I/Os are fully compliant with the Peripheral Component Interconnect SpecialInterest Group (PCI SIG) PCI Local Bus Specification, Revision 2.2 for 3.3-Voperation at 66 MHz
Supports hot-socketing
Built-in Joint Test Action Group (JTAG) boundary-scan test (BST) circuitrycompliant with IEEE Std. 1149.1-1990
ISP circuitry compliant with IEEE Std. 1532
