ACPL-352J-500E Integrated Circuit Chip Gate Drive Optocoupler 5A Logic Output Optocouplers

ACPL-352J-500E Integrated Circuit Chip Gate Drive Optocoupler 5A Logic Output Optocouplers

Product Description Of ACPL-352J-500E

ACPL-352J-500E is a 5A gate drive optocoupler device with an integrated fail-safe IGBT and MOSFET diagnostics, protection and fault reporting. The ACPL-352J-500E features common mode transient immunity (CMTI) greater than 100 kV/μs and provides minimal propagation delay with excellent timing skew. The high peak output current and wide operating voltage range eliminate the need of an output buffer circuit, enabling designers to implement cost-effective gate driver solutions for motor drives and power inverters.

Specification Of ACPL-352J-500E

Features Of ACPL-352J-500E

5.0 A maximum peak output current
4.5 A minimum peak output current
150 ns maximum propagation delay
Dual output drive to control turning on and off time
Over current detection with configurable "Soft" shutdown
Functional Safety Reporting
- Over current FAULT feedback
- IGBT/MOSFET GATE status feedback
- UVLO status feedback​
Under Voltage Lock-Out (UVLO) with Hysteresis
100 kV/μs Minimum Common Mode Rejection (CMR) at VCM = 1500 V
15V to 30V wide operating VDD2 range
–40 °C to 105 °C industrial temperature range
8.3mm creepage and clearance

Applications Of ACPL-352J-500E

IGBT and SiC/GaN MOSFET gate drive
Industrial drives and inverters
Renewable energy inverters
Switching power supplies
