DRV110APWR Integrated Circuit Chip Single Channel Relay Low-Side Driver With Integrated Current Regulation

DRV110APWR Integrated Circuit Chip Single Channel Relay Low-Side Driver With Integrated Current Regulation

Product Description Of DRV110APWR
DRV110APWR is a PWM current controller for solenoids. The device is designed to regulate the current with a well-controlled waveform to reduce power dissipation. The solenoid current is ramped up fast to ensure opening of the valve or relay. After initial ramping, the solenoid current is kept at a peak value to ensure correct operation, after which the current is reduced to a lower hold level to avoid thermal problems and reduce power dissipation.

Specification Of DRV110APWR

Features Of DRV110APWR
Internal Zener Diode on Supply Pin for High-Voltage Operation
120- and 230-V AC Supply Through Rectifier and RS Resistor
24-V, 48-V, and Higher DC Supply Through RS Resistor
Drives an External MOSFET With PWM to Control Solenoid Current
External Sense Resistor for Regulating Solenoid Current
Fast Ramp-Up of Solenoid Current to Ensure Activation
Solenoid Current is Reduced in Hold Mode for Lower Power and Thermal Dissipation
Ramp Peak Current, Keep Time at Peak Current, Hold Current, and PWM Clock Frequency Can Be Set Externally. They Can Also Be Operated at Nominal Values Without External Components.
Protection
Thermal Shutdown
Undervoltage Lockout (UVLO)
Optional STATUS Output
Operating Temperature Range: –40ºC to +125ºC

Applications Of DRV110APWR
Electromechanical Drivers: Solenoids, Valves, Relays, Contactors, Switchgear, Pneumatics
White Goods, Solar, Transportation, Smart Grid, Power Distribution
