SI8920BC-IPR Integrated Circuit Chip Isolated Amplifier For Current Shunt Measurement
SI8920BC-IPR Integrated Circuit Chip Isolated Amplifier For Current Shunt Measurement
Description
Part Number:
SI8920BC-IPR
Number Of Channels::
1 Channel
Isolation Voltage::
1200 Vrms
Isolation Type::
CMOS
3 DB Bandwidth::
950 KHz
Vos - Input Offset Voltage::
200 UV
SI8920BC-IPR Integrated Circuit Chip Isolated Amplifier For Current Shunt Measurement
Product Description Of SI8920BC-IPR
SI8920BC-IPR is a galvanically isolated analog amplifier. The low-voltage differential input is ideal for measuring voltage across a current shunt resistor or for any place where a sensor must be isolated from the control system. The output is a differential analog signal amplified by either 8.1x or 16.2x.
Specifications Of SI8920BC-IPR
1 Channel
1200 Vrms
CMOS
950 kHz
200 uV
5.5 V
3 V
4.2 mA
- 40 C
+ 125 C
Gain Error:
0.5 %
Input Type:
Differential
Moisture Sensitive:
Yes
Output Current per Channel:
3.8 mA
Output Type:
Differential
Pd - Power Dissipation:
212 mW
Vcm - Common Mode Voltage:
1 V
Unit Weight:
3 g
Feature Of SI8920BC-IPR
Low voltage differential input
±100 mV and ±200 mV options
Low signal delay: 0.75 µs
Input offset: 0.2 mV
Gain error: <0.5%
Excellent drift specifications
1 µV/°C offset drift
10 ppm/°C gain drift
Nonlinearity: 0.025% full-scale
Low noise: 0.10 mVrms over 100 kHz bandwidth
High common-mode transient immunity: 75 kV/µs
Automotive-grade OPNs available
AIAG compliant PPAP documentation support
IMDS and CAMDS listing support
Applications Of SI8920BC-IPR
Industrial Applications:
Industrial and renewable energy inverters
AC, Brushless, and DC motor controls and drives
Variable speed motor control in consumer white goods
Isolated switch mode and UPS power supplies
Automotive Applications:
Hybrid and EV traction inverters
Onboard chargers
Charging pedestals
