ADF5610BCCZ Wireless Communication Module 57MHz Wideband RF Synthesizer LGA48

ADF5610BCCZ Wireless Communication Module 57MHz Wideband RF Synthesizer LGA48​

Product Description Of ADF5610BCCZ

ADF5610BCCZ is Microwave Wideband Synthesizer with Integrated VCO. It allows implementation of fractional-N or Integer N phase-locked loop (PLL) frequency synthesizers when used with an external loop filter and an external reference source. The wideband microwave voltage controlled oscillator (VCO) design permits frequency operation from 7300 MHz to 14600 MHz at a single radio frequency (RF) output. A series of frequency dividers with a differential frequency output allows operation from 57 MHz to 14600 MHz.

Specification Of ADF5610BCCZ

Features Of ADF5610BCCZ

RF output frequency range: 57 MHz to 14,600 MHz
RFOUT: 7300 MHz to 14,600 MHz
PDIV/NDIV: 57 MHz to 14,600 MHz
Fractional-N synthesizer and Integer N synthesizer modes
24-bit fractional modulus
Exact frequency mode for 0 Hz frequency error
Typical PFD spurious: <−105 dBc
Integrated rms jitter: <40 fs
Normalized inband phase noise floor FOM
High current mode: −232 dBc/Hz (integer) and −229 dBc/Hz (fractional)
Normal mode: −229 dBc/Hz (integer) and −226 dBc/Hz (fractional)
Maintains frequency lock over −40°C to +85°C (lock and leave)
Low phase noise VCO
−115 dBc/Hz typical at 100 kHz (7.3 GHz)
−114 dBc/Hz typical at 100 kHz (10 GHz)
−109 dBc/Hz typical at 100 kHz (14.6 GHz)
RFOUT power: 5 dBm
Programmable divide by 1, 2, 4, 8, 16, 32, 64, or 128 output
Programmable output power level
Typical power dissipation: 815 mW
Programmable low current and power dissipation: <700 mW
Fast frequency hopping (autocalibration enabled): <40 μs
48-terminal, 7 mm × 7 mm LGA package: 49 mm2

Applications Of ADF5610BCCZ
Military and defense
Test equipment
Clock generation
Wireless infrastructure
Satellite and very small aperture terminal (VSAT)
Microwave radio
