TJA1145T Integrated Circuit Chip High Speed CAN Transceiver For Partial Networking SOIC14

TJA1145T Integrated Circuit Chip High Speed CAN Transceiver For Partial Networking SOIC14​

Product Description Of TJA1145T

TJA1145T is a high-speed CAN transceiver that provides an interface between a Controller Area Network (CAN) protocol controller and the physical two-wire CAN bus.
TJA1145T is designed for high-speed CAN applications in the automotive industry, providing differential transmit and receive capability to (a microcontroller with) a CAN protocol controller.

Specification Of TJA1145T

Features Of TJA1145T

Fully compliant with the ISO 11898-2:2003, ISO 11898-5:2007 and ISO 11898-6:2013 standards
Timing guaranteed for data rates up to 2 Mbit/s
Autonomous bus biasing according to ISO 11898-6:2013
Optimized for in-vehicle high-speed CAN communication
No ‘false’ wake-ups due to CAN FD frame detection in TJA1145/FD variants

Designed for automotive applications

±8 kV ElectroStatic Discharge (ESD) protection, according to the Human Body Model (HBM) on the CAN bus pins
±6 kV ESD protection, according to IEC 61000-4-2 on pins BAT and WAKE and on the CAN bus pins
CAN bus pins short-circuit proof to ±58 V
Battery and CAN bus pins protected against transients according to ISO 7637-3, test pulses 1, 2a, 3a and 3b
Suitable for use in 12 V and 24 V systems
Available in SO14 and leadless HVSON14 package (3 mm x 4.5 mm) with improved Automated Optical Inspection (AOI) capability
AEC-Q100 qualified
Dark green product (halogen free and Restriction of Hazardous Substances (RoHS) compliant)

Protection and diagnosis
16-, 24- or 32-bit SPI for configuration, control and diagnosis
Transmit Data (TXD) dominant time-out function with diagnosis
Overtemperature warning and shut-down
Undervoltage detection and recovery on pins VCC, VIO and BAT
Cold start diagnosis (via bits PO and NMS)
Advanced system and transceiver interrupt handling

Applications Of TJA1145T
Automotive Radar Solutions
Driver Monitoring Systems (DMS) and Occupant Monitoring Systems
