Product Description Of LB11600JV-TLM-E
LB11600JV-TLM-E is a direct PWM drive predriver IC appropriate for 3 phase power brushless motors in automotive applications. This IC can implement either high side PWM drive or low side PWM drive motor driver circuits depending on the configuration of the output circuits, which use discrete transistors such as MOSFETs or bipolar transistors. In addition to a full complement of protection functions, including overcurrent, thermal, motor constraint, and undervoltage protection, the LB11600JV-TLM-E also provides an integrated speed control function. Thus the LB11600JV-TLM-E can implement high reliability/high functionality drive circuits.

Specifications Of LB11600JV-TLM-E

Features Of LB11600JV-TLM-E
Three-phase bipolar drive (UH, VH, and WH pins, PWM control)
Forward/reverse switching circuit
Overcurrent protection circuit
Undervoltage protection circuit
Motor constraint protection circuit
Thermal protection circuit
Speed control circuit
