BQ76PL536ATPAPRQ1 Integrated Circuit Chip 3-To-6 Series Cell Lithium-Ion Battery Monitor And Secondary Protection IC
BQ76PL536ATPAPRQ1 Integrated Circuit Chip 3-To-6 Series Cell Lithium-Ion Battery Monitor And Secondary Protection IC
Description
Part Number:
BQ76PL536ATPAPRQ1
Output Voltage::
4.9 V To 5.1 V
Output Current::
12 UA To 22 UA
Operating Supply Voltage::
6 V To 30 V
Operating Supply Current::
45 UA
Moisture Sensitive::
Yes
BQ76PL536ATPAPRQ1 Integrated Circuit Chip 3-To-6 Series Cell Lithium-Ion Battery Monitor And Secondary Protection IC
Product Description Of BQ76PL536ATPAPRQ1
BQ76PL536ATPAPRQ1 device is a stackable battery monitor and protector for three-to-six lithium-ion cells in series. The BQ76PL536ATPAPRQ1 integrates an analog front end (AFE) along with a precision analog-to-digital converter (ADC), used to precisely measure battery cell voltages. A separate ADC is used to measure temperature.
Specifications Of BQ76PL536ATPAPRQ1
Battery Protection
Lithium-ion, Lithium Polymer
4.9 V to 5.1 V
12 uA to 22 uA
6 V to 30 V
HTQFP-64
Maximum Operating Temperature:
+ 105 C
Minimum Operating Temperature:
- 40 C
Moisture Sensitive:
Yes
Operating Supply Current:
45 uA
Features Of BQ76PL536ATPAPRQ1
Qualified for Automotive Applications
AEC-Q100 Qualified With the Following Results:
Device Temperature Grade 2: –40°C to +105°C Ambient Operating Temperature Range
Device HBM Classification Level 2
Device CDM Classification Level C4B
3-to-6 Series Cell Support, All Chemistries
Hot-Pluggable
High-Speed Serial Peripheral Interface (SPI) for Data Communications
Stackable Vertical Interface
Isolation Components Not Required Between Devices
High-Accuracy Analog-to-Digital Converter (ADC):
±1 mV Typical Accuracy
14-Bit Resolution, 6-µs Conversion Time
Nine ADC Inputs
Dedicated Pins for Synchronizing Measurements
Configuration Data Stored in Error Check/Correct (ECC)-One-Time-Programmable (OTP) Registers
Built-In Comparators (Secondary Protector) for:
Overvoltage and Undervoltage Protection
Overtemperature Protection
Programmable Thresholds and Delay Times
Dedicated Fault Signals
Cell Balancing Control Outputs With Safety Timeout
Balance Current Set by External Components
Supply Voltage Range from 7.2 V to 27 V Continuous and 36-V Peak
Low Power:
Typical 12-µA Sleep, 45-µA Idle
Integrated Precision 5-V, 3-mA LDO
Applications Of BQ76PL536ATPAPRQ1
Electric and Hybrid Electric Vehicles
Uninterruptible Power Systems (UPS)
E-Bike and E-Scooter
Large-Format Battery Systems
Other Supply Product Types
