WM8974CGEFL Integrated Circuit Chip Mono CODEC With Speaker Driver QFN24 Audio CODEC

WM8974CGEFL Integrated Circuit Chip Mono CODEC With Speaker Driver QFN24 Audio CODEC

Product Description Of WM8974CGEFL

WM8974CGEFL is a low power, high quality mono CODEC designed for portable applications such as Digital Still Camera or Digital Voice Recorder. WM8974CGEFL operates at supply voltages from 2.5 to 3.6V, although the digital supplies can operate at voltages down to 1.71V to save power. The speaker and mono outputs use a separate supply of up to 5V which enables increased output power if required.

Specification Of WM8974CGEFL

Features Of WM8974CGEFL

Mono CODEC:
Audio sample rates:8, 11.025, 16, 22.05, 24, 32, 44.1, 48kHz
DAC SNR 98dB, THD -84dB (‘A’-weighted @ 8 – 48ks/s)
ADC SNR 94dB, THD -83dB (‘A’-weighted @ 8 – 48ks/s)
On-chip Headphone/Speaker Driver with ‘cap-less’ connect
- 40mW output power into 16 / 3.3V SPKVDD
- BTL speaker drive 0.9W into 8 / 5V SPKVDD
Additional MONO Line output
Multiple analogue or ‘Aux’ inputs, plus analogue bypass path
Mic Preamps:
Differential or single end Microphone Interface
- Programmable preamp gain
- Psuedo-differential inputs with common mode rejection
- Programmable ALC / Noise Gate in ADC path
Low-noise bias supplied for electret microphones
Other Features
5 band EQ (record or playback path)
Digital Playback Limiter
Programmable ADC High-Pass Filter (wind noise reduction)
Programmable ADC Notch Filter
On-chip PLL
Low power, low voltage
- 2.5V to 3.6V (digital: 1.71V to 3.6V)
- power consumption <10mA all-on 48ks/s mode
4x4x0.9mm 24 lead QFN package

Applications Of WM8974CGEFL
Digital Still Camera Audio CODEC
Wireless VoIP and other communication handsets / headsets
Portable audio recorder
General Purpose low power audio CODEC
