TLE7185-1E Integrated Circuit Chip 80mA Gate Driver IC 3Phase Bridge Driver IC

TLE7185-1E Integrated Circuit Chip 80mA Gate Driver IC 3Phase Bridge Driver IC​

Product Description Of TLE7185-1E

TLE7185-1E is a driver IC dedicated to control the 6 to 12 external MOSFETs forming the converter for high current 3 phase motor drives in the automotive sector. It incorporates features like short circuit detection, diagnosis and combines it with typical automotive specific requirements. The TLE7185-1E is especially designed for low battery voltage and therefore it is specified down to 5.5V supply voltage. Typical applications are cooling fan, water pump, electro-hydraulic and electric power steering. The TLE7185-1E is designed for 12V power net.

Specification Of TLE7185-1E

Features Of TLE7185-1E

Drives 6 N-Channel Power MOSFETs
Separate control input for each MOSFET
Separate Source pin for each MOSFET
Integrated charge pump for operation at low battery voltages
Adjustable dead time
Shoot through protection and Shoot through option
Analog adjustable Short Circuit Protection levels
Low quiescent current mode
2 bit diagnosis / ERRx
Over temperature warning
Over voltage warning
Under voltage warning
Under voltage lockout
0 …95% Duty cycle of High Side MOSFETs

Applications Of TLE7185-1E

Fuel Pump
Water Pump
Oil Pump
Engine Cooling Fan
Eletric Power Steering
