ACPL-P480-560ME Integrated Circuit Chip High Speed Optocoupler SOP6 IC Chips

ACPL-P480-560ME Integrated Circuit Chip High Speed Optocoupler SOP6 IC Chips​

Product Description Of ACPL-P480-560ME

ACPL-P480-560ME is High CMR Intelligent Power Module and Gate Drive Interface Optocoupler.

ACPL-P480-560ME high-speed optocoupler contains an AlGaAs LED, a photo detector, and a Schmitt trigger that eliminates the requirement for external waveform conditioning circuits and the need for a pull-up resistor, which allows for a direct-drive Intelligent Power Module or gate drive.

Specification Of ACPL-P480-560ME

Wide operating temperature range: –40°C to 100°C
Maximum propagation delay tPHL/tPLH = 350 ns
Maximum pulse width distortion (PWD) = 250 ns
Propagation delay difference:
– Minimum: –100 ns
– Maximum: +250 ns
Wide operating VCC range: 4.5V to 20V
20 kV/μs minimum common mode rejection (CMR) at VCM = 1000V

Features Of ACPL-P480-560ME

Performance specified for common IPM applications over industrial temperature range
Short maximum propagation delays
Minimized pulse width distortion (PWD)
Very high common mode rejection (CMR)
Hysteresis
CMOS output (no pull-up resistor required)
Available in stretched SO-6 package

Applications Of ACPL-P480-560ME

IPM interface isolation
Isolated IGBT/MOSFET gate drive
AC and brushless DC motor drives
Industrial inverters
General digital isolation
