DIR9001PWR Integrated Circuit Chip 96-kHz 24-Bit Digital Audio Interface Receiver

DIR9001PWR Integrated Circuit Chip 96-kHz 24-Bit Digital Audio Interface Receiver

Product Description Of DIR9001PWR
DIR9001PWR is a digital audio interface receiver that can receive a 28-kHz to 108-kHz sampling- frequency, 24-bit-data-word, biphase-encoded signal. The DIR9001 complies with IEC60958-3, JEITA CPR-1205 (Revised version of EIAJ CP-1201), AES3, EBUtech3250, and it can be used in various applications that require a digital audio interface.

Specifications Of DIR9001PWR

Features Of DIR9001PWR
One-Chip Digital Audio Interface Receiver (DIR) Including Low-Jitter Clock-Recovery System
Compliant With Digital Audio Interface Standards:IEC60958 (former IEC958), JEITA CPR-1205(former EIAJ CP-1201, CP-340), AES3, EBU tech3250
Clock Recovery and Data Decode From Biphase Input Signal, Generally Called S/PDIF, EIAJ CP- 1201, IEC60958, AES/EBU
Biphase Input Signal Sampling Frequency (fS) Range: 28 kHz to 108 kHz
Low-Jitter Recovered System Clock: 50 ps
Jitter Tolerance Compliant With IEC60958-3
Selectable Recovered System Clock: 128 fS, 256 fS, 384 fS, 512 fS
Serial Audio Data Output Formats: 24-Bit I2S;MSB-First, 24-Bit Left-Justified; MSB-First 16-, 24-Bit Right-Justified
User Data, Channel-Status Data Outputs Synchronized With Decoded Serial Audio Data
No External Clock Required for Decode
Includes Actual Sampling Frequency Calculator (Needs External 24.576-MHz Clock)
Function Control: Parallel (Hardware)
Functions Similar and Pin Assignments Equivalent to Those of DIR1703
Single Power Supply: 3.3 V (2.7 V to 3.6 V)
Wide Operating Temperature Range: –40°C to 85°C
5 V-Tolerant Digital Inputs
Package: 28-pin TSSOP, Pin Pitch: 0,65 mm

Applications Of DIR9001PWR
AV/DVD Receiver, AV Amplifier
Car or Mobile Audio System
Digital Television
Musical Instruments
Recording Systems
High-End Audio/Sound Card for PC
Replacement of DIR1703
Other Applications Requiring S/PDIF Receiver
