Product Description Of MAX16916GUB
MAX16916GUB low-quiescent-current overvoltage and reverse-battery protection controllers are designed for automotive and industrial systems that must tolerate high-voltage transient and fault conditions. These conditions include load dumps, voltage dips, and reversed input voltages. The controllers monitor the input voltage on the supply line and control two external pFETs to isolate the load from the fault condition. The external pFETs are turned on when the input supply exceeds 4.5V and stay on up to the programmed overvoltage threshold. During high-voltage fault conditions, the controllers regulate the output voltage to the set upper threshold voltage, or switch to high resistance for the duration of the overvoltage transient to prevent damage to the downstream circuitry. The overvoltage event is indicated through an active-low, open-drain output, active-low OV.

Features Of MAX16916GUB
Architecture Replaces Protection Diodes Reducing the Forward Voltage, Allowing Operation During Cold-Crank Conditions
Transient Voltage Protection Up to +44V and -75V
Low-Voltage Drop when Used with Properly Sized External pFETs
4.5V to 19V Input-Voltage Operation
Ideal Diode Reverse-Battery Protection Supports Down to -75V to Protect System During Negative-Voltage Transients
Back-Charge Prevention Avoids Discharging Downstream Tank Capacitance
Overvoltage Protection Enables System to Survive Up to a +44V Load Dump
Overvoltage Indicator
Thermal-Overload Protection
Low Operating Current Meets Stringent Module Specifications While Maintaining System Protection
29µA Low Operating Current
6µA Low Shutdown Current

Applications Of MAX16916GUB
Industrial
