AS8510-ASSM Integrated Circuit Chip 16Bit Data Acquisition Front End IC SSOP20

AS8510-ASSM Integrated Circuit Chip 16Bit Data Acquisition Front End IC SSOP20​

Product Description Of AS8510-ASSM

AS8510-ASSM Data Acquisition Front End IC is a virtually offset free, low noise, 2-channel measurement device. It is tailored to accurately measure battery current from mA range up to kA range in combination with a 100 µOhm shunt resistor connected in series with the battery rail. Through the second measurement channel it enables capture of either battery voltage synchronous with the current or to measure the analog output of an internal or external temperature sensor.

Specification Of AS8510-ASSM

Features Of AS8510-ASSM

3.3V supply voltage
Redundant measurement possibility
Two high resolution 16-bit Σ−Δ A/D converters
Flexible configuration
Programmable sampling to enable data throughputs from less than 1Hz to 8kHz
Unique measurement principle
Zero offset for both channels
Wide measurement range
Independent control of data rate on both channels
On chip high-precision 4MHz RC oscillator or option for external clock
-40ºC to 125ºC ambient operation
SSOP-20 pin package

Application Fields Of AS8510-ASSM
Industrial
Robotics
Automotive and mobility
Battery management system
