L99DZ100GPTR Integrated Circuit Chip Door Zone Systems IC LQFP64 Automotive Door Module

L99DZ100GPTR Integrated Circuit Chip Door Zone Systems IC LQFP64 Automotive Door Module

Product Description Of L99DZ100GPTR

L99DZ100GPTR is door zone systems IC providing electronic control modules with enhanced power management power supply functionality, including various standby modes, as well as LIN and HS CAN physical communication layers.

Specification Of L99DZ100GPTR

Features Of L99DZ100GPTR

1 configurable high-side driver for up to 1.5 A (RON = 500 mΩ) or 0.35 A (RON = 1600 mΩ) load
1 configurable high-side driver for 0.8 A (RON = 800 mΩ) or 0.35 A (RON = 1600 mΩ) load
3 configurable high-side drivers for 0.15 A/0.35 A (RON =2 Ω)
1 configurable high-side driver for 0.25 A/0.5 A (RON = 2 Ω) to supply EC Glass MOSFET
4 configurable high-side drivers for 0.15 A/0.25 A (RON = 5 Ω)
Internal 10bit PWM timer for each stand-alone high-side driver
All the embedded outputs come with protection and supervision features:
– Current Monitor (high-side only)
– Open-load
– Overcurrent
– Thermal warning
– Thermal shutdown
Fully protected driver for external MOSFETs in H-bridge configuration or dual Half bridge configuration
Fully protected driver for external high-side MOSFET
Control block for electro-chromic element
Two 5 V voltage regulators for microcontroller and peripheral supply
Programmable reset generator for power-on and undervoltage
Configurable window watchdog
LIN 2.2a compliant (SAEJ2602 compatible) transceiver
Separated (Isolated) fail-safe block with 2 LS (RON = 1 Ω) to pull down the gates of the external HS MOSFETs
Thermal clusters
A/D conversion of supply voltages and internal temperature sensors
Embedded and programmable VS duty cycle adjustment for LED driver outputs

Applications Of L99DZ100GPTR

Door zone applications
